L1-AR+L1-Laser GNSS RTK Base+Rover – RTK GPS Handheld Collector with Software & Visual Stakeout with Camera, Global Shutter with 2 MP, 2cm Accuracy, 120° Tilt Survey | Professional Support
US$1,104.00
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by www.libaus.com.au
We aim to show you accurate product information. Manufacturers, suppliers and others provide what you see here.
US$1,104.00
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by www.libaus.com.au
Free 30-day returns Details
Product details
| Management number | 250099989 | Release Date | 2026/09/17 | List Price | US$1,104.00 | Model Number | 250099989 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- 【Centimeter RTK Performance】 Full-Frequency L1-Laser/Z1 GNSS RTK support with 1408-channel GNSS engine delivers 5-second initialization and centimeter accuracy under trees and urban canyons, supporting GPS/GLONASS/Galileo/BDS/QZSS/SBAS.
- 【Laser + GNSS Hybrid Survey】Our L1-Laser gps rtk Integrated laser enables 10m non-contact measurement for inaccessible points such as powerlines and bridge edges while maintaining centimeter precision.
- 【AR Stakeout】L1-AR gps rtk enables AR stakeout—overlaying virtual point guidance on the camera view for faster, intuitive field layout, and the handheld collector also can enables AR stakeout.
- 【Global shutter with 2 MP】L1-AR RTK features a 2MP starlight camera with 75° FOV for visual AR stakeoutCentimeter-level accuracy, reliable even in low-light conditions.Full-constellation tracking ensures fast FlX in complex environments.
- 【Simplify Your Workflow with CAD】L1 AR rtk gnss integrates CAD drawings with real-world scenes, letting youstakeout targets faster.The bottom camera ensures precise positioning as you approach.Making stakeout easier and more intuitive. Sapport DWG,DXF CAD.
- 【120° Tilt Compensation】High-grade IMU supports ±60° tilt with auto-calibration, achieving 2cm accuracy at maximum tilt for faster, pole-free topographic surveys.
- 【15km UHF Radio】 SingularXYZ L1 GNSS built-in Built-in 2W UHF transceiver provides up to 15km rover-base range and supports RTCM/CMR, compatible with third-party bases and CORS/NTRIP workflows.
- 【MORE RELIABILITY】IP67-rated magnesium alloy housing (-40°C to 65°C operating range). The IP67-rated casing of L1-Laser rtk provides protection against water, dust, and accidental drops, ensuring uninterrupted performance in the field.
- 【CLASS 3R LASER SAFETY】: L1 LASER features a Class 3R laser module with 4mW maximum output power and 520nm±20nm wavelength. Designed for professional surveying positioning assistance only. Please follow the safety instructions during operation.
- 【Note】: U.S. users must apply for an FCC radio license for commercial use (e.g., surveying, construction) with the UHF function (450–470 MHz). The device is FCC certified, and we can provide supporting info if needed. 【Special Note】The rtk gps equipment does not include the pole.
| ASIN | B0H93HB73W |
|---|---|
| Brand | SingularXYZ |
| Map Types | Worldwide |
| Item Weight | 7.8 pounds |
| Screen Size | 1 inches |
| Display Type | LED |
| Manufacturer | singularXYZ |
| BuiltIn Media | L1-AR+L1-LASER GNSS Receiver, Transport Case*1, USB-Type C Cable*2, Super Charger*2, GNSS Adapter*1 SC300 Data Collector*1, USB cable *1, Super Charger *1, Bracket*1 Whip Antenna*2, Tape Measure*1, 20 cm extention rod plugged on tribrach*1, Aluminum Plate*1 SingularPad Software*1 Quick Start Guide*1, Quick Start Card*1 |
| Number of Items | 1 |
| Compatible Devices | Data collectors |
| Additional Features | Bluetooth |
| Battery Average Life | 20 hours |
| HumanInterface Input | Buttons |
| Warranty Description | 1 year manufacturer |
| Connectivity Technology | Bluetooth |
| Memory Storage Capacity | 8 GB |
| Software Update Supported to Date | unknown |
| Supported Satellite Navigation System | BeiDou |
